Volumetric Screw feeder, Conveyor, Doser, Dispenser, Gravimetric Screw feeder, Pipe Screw feeder, Automatic Screw Feeder, Semi-Automatic Screw feeder, Powder dispenser is being manufactured by Industrial Instrumentation Services located in Dombivili, Thane, Maharashtra India.
Screw feeders are designed to meter bulk materials and are typically located at the beginning of a process. Capacity or feed rate can be accurately controlled with screw feeders. Variable speed drives improve metering accuracy and can provide a wide range of feed rates. We are manufacturer of Screw feeders as per Customer Requirements as well as special purpose screw feeders. In Special purpose screw feeder we have facility to fabricate dosing capacity in Milligram ,Gram, Kilogram & Tons. Our customer meets very accurate feeding/dosing for their applications. Our Screw feeder is used for metering/ dosing of dry material (Powder, Granules, Crystals) in either continuous or batch processing application in various industries. We provide screw feeder to various process field industries. We used superior quality raw material for manufacturing as per the product.
Screw Feeder is used for adding/dosing of free-flowing material at a controlled rate for process application. Various types of configurations are available for different types of applications. We use different material for manufacturing as per application areas like chemical, non-hazardous and hazardous. A special type of feeder is developed for the various manufacturing industry. For accurate feeding of powder, granules or crystals in process reaction and packing purpose. We are offering precise and accurate range of screw feeder that meet the various volumetric process requirements at a controlled rate. The range is also custom design as specified by client.
| Capacity | 100gm/Hr to 5Kg/Hr (As per requirements) |
| Screw RPM | RPM as per requirements |
| Feed Hopper Capacity | 1Kg to 10kg (As per requirements) |
| Min. Feed Rate per Hour | 500 gm (0.5Kg) (As per requirements) |
| Max Feed Rate per hour | 5000 gm (5.0Kg)( As per requirements) |
| Accuracy | ±2 % Appox |
| Material of construction | SS316 / 304 / M.S/ P.P (As per requirements) |
| Conveying distance | 300mm (As per requirements) |
| Non Contact parts | M.S powder coated |
| Motor Capacity | 0.5 HP |
| Power Supply | 220/440VAC, 50Hz (As per requirements) |
| Power Consumption | Max 380W |
| Dimension (mm) | 450mm(L) x 1400mm(H)x 450mm(W) Appox |
| Weight Approx With base frame | Approx 80 Kg (May Vary At Actual) |
| Rate Controller (RPM Controller) | 0.5 H.P A.C drive (As per requirements) |
